Dia.

Allowable increase
in diameter at unseized
end(max) inch

Tolerance
on diameter
(plus only)
inch

Nominal
Breaking
Load(min)
kg

Approx.
Weight
kg/100m

inch

mm

3/64

1.20

0.008

122

0.63

1/16

1.59

0.009

0.010

128

1.12

5/64

2.00

0.009

0.010

290

1.74

3/32

2.38

0.010

0.012

417

2.38

7/64

2.78

0.010

0.012

573

3.44

1/8

3.18

0.011

0.014

798

4.50

5/32

4.00

0.017

0.016

1,090

7.01

3/16

4.76

0.019

0.018

1,670

10.08

7/32

5.56

0.020

0.018

2,270

13.75

1/4

6.35

0.021

0.018

2,904

17.94

9/32

7.14

0.023

0.020

3,540

22.68

5/16

8.00

0.024

0.022

4,080

28.05

3/8

9.53

0.027

0.026

5,440

40.32

 7x19 (1+19)

1/16

2.00

0.009

0.010

218

1.12

1/8

2.38

0.010

0.012

280

2.38

3/32

3.18

0.011

0.014

798

4.32

5/32

4.00

0.017

0.016

1,090

6.00

3/16

4.76

0.019

0.018

1,678

9.67

1/4

6.35

0.021

0.018

2,903

16.40

5/16

8.00

0.024

0.022

4,082

25.75

3/8

9.53

0.027

0.026

5,443

36.16

1/2

12.5

0.033

0.030

9,676

62.34

5/8

16

0.039

0.037

15,120

120.14

7/8

22

0.048

0.052

29,635

193.11

1

25

0.050

0.060

38,710

249.36

1/32

0.79

0.006

0.003

57

0.31

3/64

1.19

0.008

0.005

131

0.71

1/16

1.59

0.009

0.006

363

2.08

5/64

1.98

0.009

0.008

363

2.08

3/32

2.38

0.010

0.009

544

2.98

7/6

2.78

0.010

0.011

726

4.02

41/8

3.18

0.011

0.013

953

5.21

5/32

3.97

0.016

0.016

1,497

8.19

3/16

4.76

0.019

0.018

2,132

11.46

7/32

5.56

0.020

0.018

2,858

15.18

1/4

6.35

0.021

0.018

3,719

20.09

9/32

7.14

0.023

0.018

4,593

25.40

5/16

7.94

0.024

0.020

5,670

31.25

3/8

9.52

0.027

0.023

8,765

45.16

7/16

11.1

0.030

0.026

11,113

61.39

1/2

12.5

0.033

0.026

14,515

77.85
